SysOn™
Bluetooth GPS basit Bluetooth sayesinde PDA ve
Notebook lara wireless navigation sistemi sağlamaktadır.
Küçük dizaynı ile kablosuz sorunsuz Notebook ve
PDA el terminallerine harita üzerine GPS datasını
rahatlıkla uygulamaktadır.
| |
|
|
|
 Wireless
navigation |
|
|
|
|
Leading
to the real navigation world |
|
|
|
|
High
Sensitivity & Precision Plus |
|
|
|
|
Excellent
GPS reception without an external antenna
|
|
|
|
|
Long
Lasting Battery Life |
|
|
|
|
With
rechargeable Lithium-polymer battery(910mAh)
|
|
|
|
|
Low
Power Consumption |
|
|
|
|
With
SiRF Star lle/LP chipset |
|
|
|
|
Compact
Design & Three LED lights |
|
|
|
|
For
convenient use |
|
|
|
|
Excellent
Compatibility |
|
|
|
|
Workable
with almost Bluetooth enabled PDA or computing
devices, and most GPS enabled mapping S/W.
|
|
|
|
|
Both
NMEA & SiRF Protocol Support |
|
|
|
|
Simply
able to switch between NMEA or SiRF output
|
GPS
Part
|
|
|
|
|
|
|
|
|
| Item
|
|
Specifications
|
| |
|
|
| |
|
|
| |
Model
Name |
|
|
SysOn
Bluetooth GPS Receiver
[Model: SOC2S03] |
| |
Chipset
|
|
|
SiRF
Star IIe/LP Chipset |
| |
Channel
|
|
|
12
Channel "All-in-View" tracking
|
| |
TTFF
|
|
|
Open
sky, stationary |
| |
Hot Start |
|
|
<
8 sec typical |
| |
Warm Start |
|
|
<
38 sec typical |
| |
Cold Start |
|
|
<
45 sec typical |
| |
Power
Consumption |
|
|
95~110mA
at 3.3 VDC
(95mA before Bluetooth connection)
|
| |
Power
Source |
|
|
Rechargeable
Lithium-polymer Battery(910mA)
|
| |
|
|
|
(Lasts
for more than 8 hours) |
| |
Protocols
|
|
|
NMEA-0183
V2.2(default) or SiRF binary |
| |
Interface
|
|
|
Baud
rate : 38,400bps |
| |
Antenna
Type |
|
|
Built-in
ceramic patch antenna |
| |
Datum
|
|
|
WGS-84
|
|
|
Compac
Flash kart sayesinde GPS içerisine gömülmüş olan
256 ve 512 MB ram ler ile GPS dünyasındaki harita
ve data sınırlamasına son verilmiştir. Özel Türkiye
haritaları ve isteyebileceğiniz daha bir çok detaylı
haritayı el bilgisayarlarına ve notebook larınıza
yer kaybetmeden sığdırabilirsiniz. Her türlü sisteme
uyumlu olan Ram + GPS modülümüz ile soket
(Yuva ) sınırlamasına son verebilirsiniz.
| Memory
& GPS in one CF card |
|
| |
|
|
The
world's first combination of flash memory
with a CF GPS receiver |
|
| |
|
|
High
GPS Reception Performance |
|
| |
|
|
Excellent
GPS reception without an external antenna
with High Sensitivity Firmware 12 Channel
parallel satellite tracking |
|
| |
|
|
Compact
& Portable |
|
| |
|
|
The
wafer-thin design and excellent mobility for
convenient use |
|
| |
|
|
Low
Power Consumption |
|
| |
|
|
Preserve
battery life |
|
| |
|
|
Excellent
Compatibility |
|
| |
|
|
Workable
with almost PDA with a Compact Flash slot
and almost GPS enabled navigation S/W |
|
| |
|
|
Both
NMEA & SiRF Protocol Support |
|
| |
|
|
Simply
able to switch between NMEA or SiRF output
|
|
| |
|
|
High
Speed Memory Write 10 Mbps |
|
| |
|
|
High
speed storage for navigation map data and
any other digital data |
Technical feature
|
|
|
|
|
|
|
|
|
| Item
|
|
Specifications
|
| |
|
|
| |
|
|
| |
Chipset
|
|
|
SiRF
Start IIe/LP High Sensitivity
|
| |
Channel
|
|
|
12
Channel parallel satellite tracking
|
| |
Frequency
|
|
|
1575.42
MHz(L1 band), C/A code |
| |
Time
To First Fix |
|
|
|
| |
Reacquisition |
|
|
0.1
second |
| |
Hot Start |
|
|
8
seconds typical |
| |
Warm Start |
|
|
38
seconds typical |
| |
Cold Start |
|
|
45
seconds typical |
| |
Positioning
Accuracy |
|
|
|
| |
Horizontal
|
|
|
10
meters, 95% typical |
| |
Vertical
|
|
|
15
meters, 95% typical |
| |
Speed
|
|
|
0.1
meter per second |
|
|
Interface
|
|
|
|
|
|
|
|
|
| Item
|
|
Specifications
|
| |
|
|
| |
|
|
| |
Interface
Type |
|
|
Compact
Flash(Type I) Multi-Function Card
(GPS + Memory) |
| |
Serial
Data Format |
|
|
4800bps,
8 bit data, 1 stop bit, no parity
|
| |
Memory
Interface |
|
|
Built-in
256 MB or 512 MB Flash Memory
|
| |
Position
Update |
|
|
Every
1 second |
| |
Protocol
|
|
|
NMEA
0183 version 3.00 |
| |
Outpout
Message |
|
|
GGA,
GSA, GSV, RMC, VTG
(Convertible to SiRF) |
|
|
| Operating
Votage |
|
| |
|
|
3.3
V DC+/- 5% |
|
| |
|
|
Environmental
|
|
| |
|
|
Operating
Temperature : 0? to 60?
Storage Temperature : -10? to 50?
Humidity : 10% to 95% (non-condensing) |
|
| |
|
|
PDA
Requirement |
|
| |
|
|
Available Compact Flash Slot
Operating System : Pocket PC 2000/2002, Window
Mobile 2003, WinCE.NET |
|
